| Distribution boom type | B5Z 31/27 |
|---|---|
| Max. Vertical reach | 30.5 m |
| Max horizontal reach | 26.2 m |
| Mast elements / folding | 5 / Z (endless rotation of arm 5!) |
| Pipelines | 125 mm double-walled |
| Min. Unfolding height | 5.7 m |
| Swivel range | +/- 270 ° |
| Pump unit type | HP 1608 EC | HP 1606 H. |
|---|---|---|
| Max. Delivery rate | 160 m³ / h | 160 m³ / h |
| Max. Concrete pressure | 80 bar | 53 bar |
| Max. Strokes / min. | 31 | 30th |
| Delivery cylinder | 230 x 2,100 mm | 230 x 2,100 mm |
| S-pipe size | 9 inches | 9 inches |
| Hydraulic circuit | closed | open |
| Tax system | electronically | hydraulically |
